Funktion-One EVO 6SH
Skeletal High Intensity Mid-High Loudspeaker
Evo 6SH skeletal loudspeaker is the mid-high section of an Evo 6, offering high output and controlled directivity from a very lightweight speaker.

High output and controlled directivity
It can be used in a wide range of applications which include providing additional coverage to an Evo 6 system, as the high power mid-high section of a multi-way PA system or in demanding speech based applications such as theatrical voice reinforcement.
Performance
- Funktion-One designed drivers
- Includes stainless steel mounting yoke
- Two-way (passive version available)
- Optional scrim for discrete appearance
- Fully horn loaded for high efficiency
- Low weight Neodymium magnets throughout
Specification
- Driver
- 1.4"
- Operating Band
- 4kHz - 18kHz
- Bandwidth (-3dB)
- 200Hz - 18kHz
- Sensitivity 1m
- 114dB at 5.6V
- Power
- 75W
- Nominal Impedance
- 32Ω
- Nominal Dispersion
- 50° Horizontal x 25° Vertical
- Connectors
- Neutrik NL4 or Junction box option
- Weight
- 20.5kg (45lbs)
